PCIe 4.0

• Support a 16GT/s bit rate
• Maintain backward compatibility
• It’s 2X bandwidth than PCIe 3.0

PCIe M.2 4.0

• Delivers lower latency
• Delivers the highest bandwidth 64Gb/s
• It’s 2 times faster than PCIe M.2 3.0

Super LAN Surge Protection

• Strengthens electrical stability
• Makes internet more stable at home
• Prevents damage from lightning strikes and electrical surges

USB 3.2 Gen1

• USB 3.2 Gen1 delivers compelling performance boosts and can be used to connect multiple devices without worrying about compatibility. It is capable of data transfer speeds up to 5Gbps and backward compatible with all existing USB products.

SATA III 6Gbps

• SATA III 6Gbps provides a higher bandwidth to retrieve and transfer HD media. With this super speed data transfer, SATA III allows an incredible data boost which is 2x faster than the SATA 3G.

HDMI 4K Connector

• Expresses bright and highly detailed content that fills the entire screen with lifelike images. Enjoying TV shows and movies online such as YouTube or Netflix through HDMI connector.

DDR4 Memory

• DDR4 Memory delivers higher performance, higher DIMM capacities, improved data integrity and lower power consumption.

Chipset

AMD B550

CPU SUPPORT

Supports AMD 3rd Gen Ryzen (Matisse) Processors / Future Ryzen Processors

Support for future AMD Ryzen processors with BIOS update

* Please refer to www.biostar.com.tw for CPU support list.

MEMORY

Supports Dual Channel DDR4 1866/2133/2400/2667/2933

Supports Dual Channel DDR4 3200(OC)/ 3600(OC)/ 4000(OC)/ 4400+(OC)

2 x DDR4 DIMM Memory Slots, Max. Supports up to 64 GB Memory

Each DIMM supports non-ECC 8/ 16/ 32 GB DDR4 module

*DDR4- 2667 only for Ryzen CPU

*Please refer to www.biostar.com.tw for Memory support list.

INTEGRATED VIDEO

By CPU model

Supports DX12

Supports HDCP

STORAGE

4 x SATA III Connectors (6Gb/s): Supports AHCI & RAID 0, 1, 10

1 x M.2 (M Key) Socket:

Supports M.2 Type 2242/ 2260/ 2280 SSD module

Supports PCI-E 4.0 x4 (64Gb/s)/ 3.0 x4 (32Gb/s)- NVMe / AHCI SSD

Supports SATA III (6.0Gb/s) SSD

*M.2 (M Key) Socket (M2_PCIE-SATA1):

The bandwidth is dependent on the CPU

Supports PCI-E 4.0 x4 (64Gb/s) speed, which depends only on Ryzen 3rd Gen Matisse.

LAN

Realtek RTL8111H

10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability

Supports Super LAN Surge Protection

CODEC

ALC887

7.1 Channels, High Definition Audio, Hi-Fi (Front)

USB

8 x USB 3.2 (Gen1) ports (4 on rear I/Os and 4 via internal headers)

6 x USB 2.0 ports (2 on rear I/Os and 4 via internal headers)

EXPANSION SLOT

1 x PCIe 4.0/ 3.0 x16 Slot:

Supports PCIe 4.0 x16 mode with AMD Ryzen processors. (Matisse only)

Supports PCIe 3.0 x16 mode AMD Ryzen with Radeon Vega Graphics processors.

2 x PCIe 3.0 x1 Slots

*According to different CPUs will have different speeds.

REAR I/O

1 x PS/2 Keyboard

1 x PS/2 Mouse

1 x HDMI Port

1 x VGA Port

1 x LAN port

4 x USB 3.2 (Gen1) Ports

2 x USB 2.0 Ports

3 x Audio Jack

INTERNAL I/O

4 x SATA III (6.0Gb/s) Connectors

2 x USB 2.0 Headers (each header supports 2 USB 2.0 ports)

2 x USB 3.2 (Gen1) Headers (each header supports 2 USB 3.2 (Gen1) ports)

1 x 8-Pin Power Connector

1 x 24-Pin Power Connector

1 x CPU Fan Connector

1 x System Fan Connector

1 x Front Panel Header

1 x Front Audio Header

1 x Clear CMOS Header

1 x Internal Stereo Speaker Header

1 x COM Port Header

H/W MONITORING

CPU / System Temperature Monitoring

CPU / System Fan Monitoring

Smart / Manual CPU Fan Control

System Voltage Monitoring

DIMENSION

Micro-ATX Form Factor: 24.4 cm x 20.8 cm

OS SUPPORT

Windows 10 (64bit)

*BIOSTAR reserves the right to add or remove support for any OS with or without notice.

ACCESSORIES

2 x SATA Cables

1 x I/O Shield

1 x Quick Guide

1 x DVD Driver
